2 Lanes Chicken Bag Side Sealing Bag Machine
MGA-06-800CB2
Features
Ming Jilee's 2-Lanes Chicken Bag Side Sealing Machine features a Japanese-made servo motor for precise size control, ensuring consistent quality across all bags. The dancing roll station, powered by an AC motor with inverter speed control, offers flexible and efficient operation. This side sealing machine excels in high-speed sealing, effectively handling curved shapes and removing waste with a built-in suction unit. The adjustable holes puncher allows for easy distance adjustments to achieve perfect alignment. Additionally, the strong sealing bar ensures clean cuts and superior sealing quality, making it a reliable choice for various sealing needs.
Gallery
Specifications
swipe your finger
| Model | MGA-06-800CB2 | |
| General Machine Specifications | ||
| Machine Dimension | 7,600 (L) × 1,700 (W) × 1,960 (H) mm | |
| Machine Weight | 2,390 kg | |
| Required Power | 7KW | |
| Machine Performance | ||
| Feed Material | PE Blown Film | |
| Thickness Range | 0.02 - 0.08 mm | |
| Effective Width Of Bag for Side Seal | 75 - 800 mm | |
| Effective Chicken Bag Length for Twin Lines | Max. 350 mm | |
| Effective Chicken Bag Length for Single Line | Max. 700 mm | |
| Output (Chicken Bag) | 120-260 pcs/min. | |
