Flower Bag Making Machine with In-Line Heat Dotting Device

MGA-22A-800D

Flower Bag Making Machine with In-Line Heat Dotting Device

Features

The Flower Bag Making Machine with In-Line Heat Dotting Device by Ming Jilee uses a Japan-made servo motor for precise size control of flower bags and sleeves. Equipped with two dancing roll stations, it ensures optimal tension during production. The heat sealing bar station features a linear bearing slider, designed by Ming Jilee, allowing for easy size adjustments. With a pin stacking station and auto conveyor system, operators can directly collect the finished flower bags or sleeves for the next packaging process. Ming Jilee also offers an optional USA-made punching station for creating holes in the flower bags or sleeves, ensuring top-notch quality.

Specifications

swipe your finger

Model MGA-22A-800D
General Machine Specifications
Machine Dimension 10,920 (L) x 1,710 (W) x 1,910 (H) mm
Machine Weight 4,900 kg
Required Power 7 kw
Machine Performance
Feed Material CPP, BOPP
Single Layer Film Thickness 0.028 - 0.08 mm
Output 60 - 110 bags/min
