High Speed Sheet Protector Machine with Small Q’ty Packing System
MGA-17A-700DSPEX+17P2-355-A
Features
The High-Speed Sheet Protector Machine with Small Q-ty Packing System by Ming Jilee features two production lanes, each controlled by four sets of servo motors for stable and efficient output. The machine is equipped with a fully automatic white strip system, reducing the time required for reloading new ribbons. Its latest precision punching mold allows for high-speed production, while the stable heat sealing station ensures excellent sealing quality at the bottom of the sheet protectors. Additionally, the machine includes an auto packing system to save labor costs, improving overall productivity.
Gallery
Specifications
swipe your finger
| Model | MGA-17A-700DSPEX+17P2-355-A | |
| Machine Dimension | 10,350 (L) × 3,770 (W) × 2,200 (H) mm | |
| Power Preparation | 27 kw | |
| Feed Material | CPP & PP Blown Film | |
| Thickness Range | 0.03 - 0.1 mm | |
| Size Range | A4 | |
|
Output (With Packing System) a. 25 pcs per bag b. 10 pcs per bag |
Same Direction Packing 300 - 400 pcs/min 160 - 200 pcs/min |
|
