High Speed Twin lines sheet protector making machine

MGA-17A-700DSPEX

High Speed Twin lines sheet protector making machine

Features

The High-Speed Twin Lines Sheet Protector Making Machine by Ming Jilee is equipped with four sets of servo motor controls to ensure stable production across two lanes. Its fully automatic white strip design includes an auto-connecting system that reduces the time spent reloading the ribbon, enhancing efficiency. The latest precision punching mold enables high-speed production, while the stable heat sealing station ensures excellent sealing quality at the bottom of the sheet protectors. Additionally, the machine features an auto packing system, helping to reduce labor costs and improve overall productivity.

Specifications

swipe your finger

Model MGA-17A-700DSPEX
Feed material CPP & Blown Film
Thickness (by gauge measure) 0.03 - 0.1 mm
Effective cutting size A4, FC (A5 is required punching mold)
Output 280 - 400 pcs/min (depend on thickness)
Machine Dimension 8,340 (L) x 2,520 (W) x 2,220 (H) mm
Machine Weight 5,060 kg
Required Power 30 kw
Actual power consumption 12 kw
